Class A Half Cell 450W Monocrystalline Pv Panels 9BB 144 Cell

Product Categories
Anhui Sunerise Energy Co., Ltd
Contact Now

Class A Half Cell 450W Monocrystalline Pv Panels 9BB 144 Cell

  • 1
  • 2
  • 3

Brand Name : SUNERISE

Model Number : JC450-144M

Certification : TUV,CQC,CE,IAF,CNAS,ISO etc

Place of Origin : Hefei,China

MOQ : 30pcs

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 1MW,1Month

Delivery Time : 5-7 work days

Packaging Details : 30pcs/palle, packed in cartons

Size : 2094*1038*35mm

Current : 10.69A

Model : JC450-144M

Efficiency : 20.7%

Waterproof Grade : IP68

Fireproof Grade : Fireproof Grade

Package size : 2110*1130*1180mm

Package weight : 695Kg

Contact Now

Class A PV half cell 450W MONO 9BB 144 cell solar panels

Monocrystalline Solar Panel

Class A PV half cell 450W MONO 9BB 144 cell solar panels


Features:
Mono cells are more efficient
Low current density, lower power consumption of components
9BB and half cell technology to reduce the impact of crack and occlusion on component power generation
Lower prices and greater efficiency.


Maximum Power at STC [Pmax] 450W
Open Circuit Voltage [Voc] 50
Short Circuit Current [Isc] 11.47
Voltage at Maximum Power Point [Vm] 41.4
Current at Maximum Power Point [Im] 10.97
Power Tolerance 0~+5W
Module Efficiency 20.22
Maximum Power at NOCT [Pmax] 333.6
Open Circuit Voltage [Voc] 42.7
Short Circuit Current [Isc] 8.73
Voltage at Maximum Power Point [Vm] 38.3
Current at Maximum Power Point [Im] 8.73
Values at Standard Test Conditions STC Air Mass AM1.5,irradiance 1000W/㎡ ,Cell Temperature 25℃
NOCT Irradiance at 8000W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s


Product details:
1. Adopt advanced technology and production equipment to ensure reliable and stable power output and a service life of up to 25 years.
2, every 18, 36, 60, 72 crystal silicon solar cell series installed a bypass diode, can effectively prevent the hot spot effect.
3. The use of deep black silicon nitride layer with high photoelectric conversion efficiency as anti-reflection film, to ensure the good appearance of the module.
4, Made of high strength, low iron and high light transmittance tempered glass, anti-aging EVA (polyethylene vinyl acetate), high photoelectric conversion efficiency, high reliability, high performance
Crystal silicon solar cell, TPT (composite fluorine plastic film) laminated with excellent weather resistance, has good weather resistance, hail resistance and waterproof ability.
5, No screw built-in Angle chain connection, fastening seal, high mechanical strength.
6, the use of sealed waterproof multifunctional junction box, to ensure the safety of components.


Manufacturing Technique

Class A Half Cell 450W Monocrystalline Pv Panels 9BB 144 Cell         Class A Half Cell 450W Monocrystalline Pv Panels 9BB 144 CellClass A Half Cell 450W Monocrystalline Pv Panels 9BB 144 CellClass A Half Cell 450W Monocrystalline Pv Panels 9BB 144 Cell

FAQ
1.Q:Do you have your own factory?
A:Yes, we are professional manufacturer mainly in solar panel for many years. Our factory is located in Hefei, Anhui, China.
2.Q:What kind of certification you have?
A:ISO9001,ISO14001,ISO18001, TUV,CQC,CE,CEC,UL and so on.
Our products could pass different labor testing according to different countries' requirements.
3.Q:Where we can use the system?
A:You can use the system for home, for power station, for lighting system and so on, wnere the grid power is expensive.
4.Q:How about your warranty?
A: We provide 1.5 and 3 years warranty for different products and whole life technical support.
5.Q:Competitive Price
A:All of our products are produced by our own factory. So the price is very copetitive.
6.Q:How to do the installation?
A: This portable solar system installation is very simple, only need to connect solar panel with controller, and push ON/OFF button, then it will start to work.
7.Q:24-hours online service
A: Please feel free to contact us. Our sales team will provide you with 24 hours better pre-sale.
